Electrostatic Ring(TC-27)
Insulation transformer paperboard is made from 100% high-quality sulfate insulation wood pulp. This paperboard contains no fillers and is not graded by size. The paper undergoes thorough reprocessing and cleaning to ensure uniform thickness and structure.
Product Description
Specifications and models are customized according to customer requirements.
Manufacturing Process：
Material Preparation → Soaking → Veneer Cutting → Drying → Finishing → Bonding → Pre-Pressing → Hot Pressing
Scope of Application：
Electrical laminated wood is a high-performance insulating structural material widely used in core power equipment such as transformers and instrument transformers. It is made from high-quality birch veneers through multiple impurity-removal processes, enabling long-term stable operation in the harsh environments of power systems. It features outstanding electrical performance advantages: its dielectric constant is extremely close to that of transformer oil, and it can withstand the combined effects of strong mechanical force and high-intensity electric field. It is suitable for long-term operation in oil-immersed transformers with a maximum temperature of 105°C. It can replace steel plates, epoxy boards and other materials to manufacture insulating clamps for instrument transformers, reducing weight and costs while improving the insulation safety margin, and meeting both mechanical and insulating performance requirements at the same time.
Send Your Drawing or
Insulation Material
Requirement
Please provide material, size, drawing, operating condition and quantity for quotation.
